Swan Agro MB Plough can handle the toughest ploughing job with outstanding penetration performance. This plough has special wear –resistance steel blade and bar points. These plough are designed by experts and can be easily mounted on tractor directly with ease.
Available in size 2 furrow, 3 furrow & 4 furrow.
Features
- Sturdy structure with less weight.
- Specially designed Leakproof Aluminum casting Gear Cover.
- Baldes are Tempered & made of Boron Steel from Italy. Available with L-Type or C-Type Blades- Interchangeable.
- Export Quality Heavy Duty Gear Box.
- Nut and Bolt is made of High Tensile Steel (10.9 Grade).
- Side Transmission is driven through Gears providing Smooth Drive & Longer Service Life.
- Save Fuel & Time.
- Available from 1.40mtr to 2.00 mtr size for 30 H.P to 60 H.P tractors.
Advantages
- Best to be used for Secondary Tillage operation.
- Specially designed for wet land, light & medium duty operations.
- By combining disking, cultivating and planking, rotavator prepares soil quickly for sowing.
- Rotary Tiller helps in reducing tractor’s wear and tear, save fuel & time, maintain the moisture of the soil.
- Rotary tiller prepares all type of soil – Wet & Dry.
- Stubbles and residue of previous crop is chopped into pieces and thoroughly mixed in soil to form organic manure.
- Rotary Tiller is extremely helpful in Sugar Cane, cotton, Paddy and Vegetables cultivation.
- Heavy Duty PTO Shaft with Shear Bolt for overload protection.
Technical Specifications
| wdt_ID | Description/ Models | NSEGY RT 140 | NSEGY RT 160 | NSEGY RT 180 | NSEGY RT 210 |
|---|---|---|---|---|---|
| 1 | Overall Width (mm) | 1700 | 1900 | 2100 | 2300 |
| 2 | Tillage Width (mm) | 1400 | 1600 | 1800 | 2000 |
| 3 | Tillage Depth (mm) | 120 - 150 | 120 - 150 | 120 - 150 | 120 - 150 |
| 4 | Gear Box | Single Speed/ Multi - Speed | Single Speed/ Multi - Speed | Single Speed/ Multi - Speed | Single Speed/ Multi - Speed |
| 5 | Side Transmission | Gear Drive | Gear Drive | Gear Drive | Gear Drive |
| 6 | PTO Speed (Rpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| 7 | No. of Blades | 42 | 48 | 54 | 60 |
| 8 | Blade specifications | L type 4" | L type 4" | L type 4" | L type 4" |
| 9 | Weight(Kgs. Approx.) | 350 | 370 | 390 | 410 |
| 10 | Tractor Power (H.P) | 30 - 35 | 35 - 45 | 45 - 50 | 50 - 60 |
